Turbo side channel Blower (Single Stage)
| Item : | E-13 | Model : | TBM-229 |
| Rated Output : | 0.4kw / 0.5hp (kw) | Voltage : | 220-240 (V) |
| Current : | 2.5 (A) | Voltage : | 345-415 (V) |
| Max Volume : | 90 m3/hr (M3/min) | Noise : | 58 Db (Db) |
| Weight : | 12 kg (kg) | ||
| SuctionFilter | 1.1/4" |
Description
The Turbo Side channel Blower Single stage series models are for Various applications.
The use of Turbo side channel blowers is common in machine-building as high pressure ventilator, vacuum pump, air pump, booster, low pressure compressor and oil-free compressor. The applications are unlimited like Aquaculture, aireating, dust cleaning, vacuum lifting, vacuum tables, blowing off, pneumatic transport, cooling and vacuum molding.
Turbo Die cast aluminium side channel blowers are robust units used for versatile applications. These blowers stand out for their durability, due to the robust aluminium design, which makes them highly resistant against corrosion. Other advantages of Turbo side channel ventilators include:
- Almost completely maintenance free
- Have a wide range of performance
- Robust yet light weight
- Reliability - Built to last
- 50/60 Hz Voltage range motors
- Low level of noise
- Easy installation
- No vibration, complete dynamic stability
- Pulsation free discharge
- Simple and minimal maintenance
- Higher Pressure Ratios
- Cooler Running Bearings
- Longer Grease Life
- 100% Oil Free Air
- Suitable to environment protection
- Small dimensions
